Wall Mount with "H" Back Plate Adjustable Premier Series Hinge

Wall Mount with "H" Back Plate Adjustable Premier Series Hinge

  • Adjustable Solid Forged Brass Shower Door Hinges With Rounded Corners and Beveled Edges
  • Adjustable Feature Allows for Adjustment of Door Closing Position After Installation
  • Matching Finish Stainless Steel Allen Style Clamp Screws (Phillips Screws Available Upon Request)
  • Self-Centering 0° Return with Adjustment Up to 30° In or Out
  • Solid Forged Brass Construction
  • Precision Machined 300 Series Stainless Steel Components
  • Dual Precision Wound Stainless Steel Return Springs
  • Self-Closing from 25 Degrees
  • Mouse Ear Design
  • Designed for 3/8" and 1/2" (10 and 12 mm) Glass
  • Wall Mount Hinges Include Matching Finish Stainless Steel Mounting Screws
  • Allen Wrench Included
  • Rated at 40 lbs (18 kg) per Hinge

ADDITIONAL PRODUCT INFORMATION: Using two hinges with 3/8" to 1/2" glass the hinges will hold up to 80 lbs (36 kg) with a maximum door width of 30".  Using three hinges with 3/8" to 1/2" glass the hinges will hold up to 120 lbs (54 kg) with a maximum door width of 36".**Adjustable Angle Instructions Steps: 1. Use 3 mm Hex Wrench (A) to loosen two screws (B) by turning one circle counter-clockwise. Then proceed with the adjustment. 2. Once you have aligned the door, re-tighten two screws (B).

Select Finish
From $20.29

Original: $67.62

-70%
Wall Mount with "H" Back Plate Adjustable Premier Series Hinge—

$67.62

$20.29

Product Information

Shipping & Returns

Description

  • Adjustable Solid Forged Brass Shower Door Hinges With Rounded Corners and Beveled Edges
  • Adjustable Feature Allows for Adjustment of Door Closing Position After Installation
  • Matching Finish Stainless Steel Allen Style Clamp Screws (Phillips Screws Available Upon Request)
  • Self-Centering 0° Return with Adjustment Up to 30° In or Out
  • Solid Forged Brass Construction
  • Precision Machined 300 Series Stainless Steel Components
  • Dual Precision Wound Stainless Steel Return Springs
  • Self-Closing from 25 Degrees
  • Mouse Ear Design
  • Designed for 3/8" and 1/2" (10 and 12 mm) Glass
  • Wall Mount Hinges Include Matching Finish Stainless Steel Mounting Screws
  • Allen Wrench Included
  • Rated at 40 lbs (18 kg) per Hinge

ADDITIONAL PRODUCT INFORMATION: Using two hinges with 3/8" to 1/2" glass the hinges will hold up to 80 lbs (36 kg) with a maximum door width of 30".  Using three hinges with 3/8" to 1/2" glass the hinges will hold up to 120 lbs (54 kg) with a maximum door width of 36".**Adjustable Angle Instructions Steps: 1. Use 3 mm Hex Wrench (A) to loosen two screws (B) by turning one circle counter-clockwise. Then proceed with the adjustment. 2. Once you have aligned the door, re-tighten two screws (B).
