180º Glass to Glass Americana Series Hinge

180º Glass to Glass Americana Series Hinge

  • Finished to Match Stainless Steel Phillips Style Clamp Screws
  • Self-Centering 0° Return
  • Solid Forged Brass Construction
  • Precision Machined 300 Series Stainless Steel Components
  • Dual Precision Wound Stainless Steel Return Springs
  • Self-Closing from 25 Degrees
  • Mouse Ear Design
  • Designed for 3/8" or 1/2" Glass
  • Wall Mount Hinges Include Finished to Match Stainless Steel Mounting Screws
  • Rated at 40lbs Per Hinge

ADDITIONAL PRODUCT INFORMATION: Using two hinges the hinge will hold up to 80 lbs (36 kg) with a maximum door width of 30" (762 mm). Using three hinges the hinge will hold up to 120 lbs (54 kg) with a maximum door width of 36" (914 mm).

The Americana 180° Glass-to-Glass Series of professional Hinges is able to accommodate 3/8" (10 mm) to 1/2" (12 mm) glass. Americana Hinges are self-centering and contain a Reversible 5 ° Pivot Pin. Made of solid brass with all moving parts (pins and springs) in stainless steel.

Select Color
From $21.07

Original: $70.22

-70%
180º Glass to Glass Americana Series Hinge—

$70.22

$21.07

Product Information

Shipping & Returns

Description

  • Finished to Match Stainless Steel Phillips Style Clamp Screws
  • Self-Centering 0° Return
  • Solid Forged Brass Construction
  • Precision Machined 300 Series Stainless Steel Components
  • Dual Precision Wound Stainless Steel Return Springs
  • Self-Closing from 25 Degrees
  • Mouse Ear Design
  • Designed for 3/8" or 1/2" Glass
  • Wall Mount Hinges Include Finished to Match Stainless Steel Mounting Screws
  • Rated at 40lbs Per Hinge

ADDITIONAL PRODUCT INFORMATION: Using two hinges the hinge will hold up to 80 lbs (36 kg) with a maximum door width of 30" (762 mm). Using three hinges the hinge will hold up to 120 lbs (54 kg) with a maximum door width of 36" (914 mm).

The Americana 180° Glass-to-Glass Series of professional Hinges is able to accommodate 3/8" (10 mm) to 1/2" (12 mm) glass. Americana Hinges are self-centering and contain a Reversible 5 ° Pivot Pin. Made of solid brass with all moving parts (pins and springs) in stainless steel.
